Fully continuous waste tyre(plastic)pyrolysis plant

Internal screw rotatory pyrolysis. No coking.
Hot melt processing in advance, process generated HCL specially, more environmental protection
Adopt multilevel cooling design, to get more fuel oil.
Hot air heat, cooperated with low temperature pyrolysis catalyst, extend working life of plant.
Enclosed production all the way, no leakage and no dust loss, environmental protection.
Exhaust gas multistage processed, gas emission reach European Standard level.

Waste plastic and medical waste sent into fuel preheater by conveyor to melt. Process generated HCL specially.
Melted fuel continuously sent into reactor, and finish pyrolysis under low pressured catalyst.
After generated gas during pyrolysis separates in gas-liquid separator, liquify in condenser and get fuel oil. After fixed bed second catalyst and dewaxing , can get the fuel oil with high quality.
Carbon residue after pyrolysis output continuously by cooling conveyor, and made to be carbon rod as fuel.
Flammable gas goes into exhaust gas treatment tank to desulfur, then extracted by vacuum pump and enter into water sealed tank, sent to hot air stove to burn.

Item	30 T fully continuous waste tyre pyrolysis plant
Type	XFLJ--30
Capacity	30T/D
Operating temperature	≤650°
Material	Q345R
Fuel consumption in start	400 kg
Fuel consumption in operation	0 (the syn gas from the system be burnt by the system itself)
Heating way	Hot air circulation heating
Tire requirement	Tyre piece ≤20mm
Working pressure	Normal pressure
Methods of flame retardant	Nitrogen Blow
Total power	190 kw
Running power	190 kw/h
Boundary dimension	14000mm(L) × 2400mm(W) ×4000mm(H) × 2
Floor space	36000 mm ×8000 mm
The highest install elevation	7000 mm
Labor	2-3 people
Working life	5-7 year
